U Channel Groove Square Ventilation Roll Forming Equipment 30m/Min

Name: U Channel Groove Square Ventilation Roll Forming Equipment 30mMin
Brand: Sussman
Price: 1 USD

Wholesale U Channel Groove Square Ventilation Roll Forming Equipment 30m/Min from china suppliers

Brand Name : Sussman

Model Number : SM-RM

Certification : SGS, ISO9001, CE

Place of Origin : Wuxi Jiangsu China

MOQ : 1 set

Price : negotiable

Payment Terms : L/C, T/T

Supply Ability : 10 sets per month

Delivery Time : 60 days after deposit

Packaging Details : Standard packing

Material : 0.4-0.7MM PPGI GI

Forming speed : 0-30m/min

Forming stations : About 20 stations

Transmission : chain drive

Main Power : 11KW

Material of Cutting Knife : Cr12Mov, Quench HRC58-62

Usage : Roof ceiling

Voltage : 380V 50HZ 3Phase

Contact Now

20 Stations U Channel Groove Square Ventilation Roll Forming Machine With Speed 30m/min

Technical parameter

Item	Technical data
Steel sheet thickness	0.4-0.7mm (depend on requirement )
Hydraulic power	7.5kw
Transmission way	Chain
Capacity of Decoiler	3 Tons passive
Roller Material	Gcr15, Quench HRC58-62 Plated Chrome
Roller Diameter	75mm
Principal Axis	45# high grade steel with quenching treatment
Main Motor Power	11Kw
Dimension	95008001200mm
Weight	8 Tons
PLC	Delta
Touch Screen	Delta
Electric parts	Schneider

Main Components

S.N	Equipment name	Quantity
1	3 T passive un-coiler	1 set
2	Main roll forming machine	1 set
3	Following cutting device	1 set
4	Hydraulic station	1 set
5	Control system	1 set
6	4 Meters out table	1 unit
7	Spare parts	1 package
8	Safety cover	1 set

Ceiling Channel Machine Working Flow

With aluminum sheet as raw material, uncoiling—roll forming—cut to length—auto unloading.
Lift sheets to uncoiler with forklift or crane, then manual guide material to roll forming machine for continuous roll forming, rotary encoder for length setting and auto shearing, then next sheet will push product out, whole production auto continuously production.

Machine Photo
U Channel Groove Square Ventilation Roll Forming Equipment 30m/Min
