High Main Motor Power 7.5 KW Fence Post Roll Forming Machine With Chain Drive

Name: High Main Motor Power 75 KW Fence Post Roll Forming Machine With Chain Drive
Brand: Sussman
Price: 19500 USD

Wholesale High Main Motor Power 7.5 KW Fence Post Roll Forming Machine With Chain Drive from china suppliers

Brand Name : Sussman

Model Number : SS-FP

Certification : CE, SGS, ISO

Place of Origin : China (Mainland)

MOQ : one set

Price : USD19500-USD23500 Per set

Supply Ability : 10 sets/ month

Delivery Time : 61 working days after deposit

Packaging Details : Standard package with film, plastic and steel wire. (or customized)

Forming stations : About 12 stations

Roller material : 45# Steel with quenching 60mm shaft

Dirve system : 1.5 inch chain

Power supply : 380V, 50Hz, 3Phase

Forming speed : 10m/min

Control system : PLC with touch screen

Material Thickness : 0.9-1.0mm steel coils

Material Of Cutting : CR12 with quench treatment

Electric Source : 415V, 50HZ,3 phase Also can satisfy Customer’s require

Contact Now

High Main Motor Power 7.5 KW Fence Post Roll Forming Machine With Chain Drive

Technical Parameter

Item NO.	Description	Offered specification
1.0	Roll forming machine
1.1	Rolling speed	6--9 m per min(not include cutting time)
1.2	Rolling thickness	0.8mm--1.5mm
1.3	Raw material	Galvanized steel sheet
1.4	dimension	12000mm1200mm900mm
1.5	Effective width	200mm
1.6	Roller stations	About 22stations
1.7	Roller material	45# steel, coated with chrome, Quenching
1.8	Shaft diameter	Φ70mm ,material is 45# forge steel
1.9	Transmission	Gearbox
1.10	Material of chain	45# forged steel with frequency quenching, 12A
1.11	Material of cutting	Cr12Mov with quench HRC58-62°
1.12	Cutting Tolerance	6m+- 0.5mm

Main Components

S.N	Equipment Name	Quantity
1	3T Manual Decoiler	1 set
2	Leveling device	1 set
3	Servo feeding device	1 unit
4	Press machineJH 21-63	1 unit
5	Main roll forming machine	1 set
6	Cutting holder	1 set
7	Hydraulic station	1 set
8	Control system ( including control box)	1 set
9	Out tables	2 sets
10	Spare parts	1 package
11	Cutting dies	1 set
12	Punching die	1 set

Working Flow of Roll Forming Machine

A. Passive Decoiler..........................................................To load and uncoiling material

B. Servo Feeding Applicator............................................To feed the material accurately

C. Hydraulic/Press Punching...........................................To punch as requirements

D. Roll Forming Unit.........................................................To roll form as requirements

E. Hydraulic Cutting.........................................................To cut sheets as desired length

F. Output Table................................................................Support the finished products

Decoiler----feedingwithguide---Punching----Rollforming----Cutting----Products collecting

High Main Motor Power 7.5 KW Fence Post Roll Forming Machine With Chain Drive

Main profile drawing show

High Main Motor Power 7.5 KW Fence Post Roll Forming Machine With Chain Drive

Machine Components

High Main Motor Power 7.5 KW Fence Post Roll Forming Machine With Chain Drive
